Dencryl Roof Deck System OS 10

(4.5-6.5 mm)

Fast curing roof deck coating system with separate, manually applied waterproofing membrane and wear coat with enhanced crack bridging properties (class B 4.2) and lVT+V (-20°C) for exposed roofs with pedestrian and vehicle traffic. According to RILI SIB 2001, class OS 10 and DIN 18532 Part 1 and 6.







Benefits

  • High Impact & Abrasion Resistance
  • Many colors
  • Adhesion to all horizontal and vertical surfaces
  • Risk free installation
  • Reduces inside temperature
  • Heat reflective
  • Fast and low temperature curing (2 hours)
  • Increased dynamic crack bridging class B4.2 at -20°C
  • Resistant to oils, petrol, diesel and de-icing salt
  • Anti-slip properties for pedestrians and vehicles
  • Seamless application
  • Improves the efficiency of roof installed solar panels
  • No open fire during installation
  • Expected lifetime more than 30 years

Applications

A weatherproof & UV Resistant heavy duty roof deck coating system designed for outdoor roof parking areas. The system consists of 2 separate layers of membrane, a fiber reinforced fleece and a strong and very durable top layer. The system offers excellent crack bridging properties and flexibility. Due to the unique properties of the PMMA binder, the system can be installed in only 2 hours, regardless the temperatures.

Scope of use

  • Roofing
  • Parking decks

Application conditions

  • Temperature -30ºC to 30ºC, best 15 to 25ºC, max. moisture content in the concrete subfloor 5% by weight.

Appearance

  • Dencryl Roof System is a single colored smooth or antislip Roof membrane system

Temperature Resistance

  • Dencryl Roof System is resistant to temperature cycles up to 80°C. Extended periods at these temperatures and above will make material susceptible to chemical attack and abrasion wear.

Life Expectancy

  • More than 30 years

Colours

  • See separate color chart.
Dencryl  Roof  Deck System OS 10
Roof Deck OS 10
CE

System Build-up

LAYER PRODUCT CONSUMPTION (kg/m²) INTERMEDIATE THICKNESS (mm) APPLICATION
Primer Dencryl P11/P12 (Depending on substrate) 0.3 - 0.5 Light sand scatter 0.3 - 0.8mm on wet surface Min 0.3 Roller or rubber squegee
Membrane Dencryl CM 42 Pro 2.0 - 2.5 None Min 2.0 Notched rubber squegee
Membrane Dencryl CM 42 Pro 2.0 - 2.5 Reinforced fiber fleece Min 2.0 Notched rubber squegee
Wear Coat Dencryl CS32 - Pro 3.5 - 4.0 None 2.0 - 2,5 Trowel and notched rubber squeegee

Technical Data

Properties

Value

System thickness

Aproxx 4 - 6.5 mm

Adhesive strength at Tnorm DIN EN 1542

≥ 4.0 N/mm2

Adhesive strength after freeze-thaw with de-icing salt DIN EN 13687-1 and -2

≥ 2.3 N/mm2

Dynamic crack bridging (-20°C) DIN EN 1062-7

lVT+V (B4.2)

Grip and slip resistant DIN EN 13036-4, DIN 51130

55 Skt R11-V4 and R12-V6 or R13 V10

Chemical resistance DIN EN 13529

Test liquids DiBT No. 1, 3, 10

Abrasion resistance (H22 Wheel) DIN ISO 9352, ASTM D 1044

<1500 mg/1000 U

Impact resistance DIN EN ISO 6772-2

4 Nm - no cracks

Fire class EN 13501-1

Bfl-s1

Colours

Yellow
Buff
Red
Blue
Dark Green
Dark Grey
Light Grey
White
