(4.5-6.5 mm)
Fast curing roof deck coating system with separate, manually applied waterproofing membrane and wear coat with enhanced crack bridging properties (class B 4.2) and lVT+V (-20°C) for exposed roofs with pedestrian and vehicle traffic. According to RILI SIB 2001, class OS 10 and DIN 18532 Part 1 and 6.
A weatherproof & UV Resistant heavy duty roof deck coating system designed for outdoor roof parking areas. The system consists of 2 separate layers of membrane, a fiber reinforced fleece and a strong and very durable top layer. The system offers excellent crack bridging properties and flexibility. Due to the unique properties of the PMMA binder, the system can be installed in only 2 hours, regardless the temperatures.
LAYER | PRODUCT | CONSUMPTION (kg/m²) | INTERMEDIATE | THICKNESS (mm) | APPLICATION |
---|---|---|---|---|---|
Primer | Dencryl P11/P12 (Depending on substrate) | 0.3 - 0.5 | Light sand scatter 0.3 - 0.8mm on wet surface | Min 0.3 | Roller or rubber squegee |
Membrane | Dencryl CM 42 Pro | 2.0 - 2.5 | None | Min 2.0 | Notched rubber squegee |
Membrane | Dencryl CM 42 Pro | 2.0 - 2.5 | Reinforced fiber fleece | Min 2.0 | Notched rubber squegee |
Wear Coat | Dencryl CS32 - Pro | 3.5 - 4.0 | None | 2.0 - 2,5 | Trowel and notched rubber squeegee |
Properties
Value
System thickness
Aproxx 4 - 6.5 mm
Adhesive strength at Tnorm DIN EN 1542
≥ 4.0 N/mm2
Adhesive strength after freeze-thaw with de-icing salt DIN EN 13687-1 and -2
≥ 2.3 N/mm2
Dynamic crack bridging (-20°C) DIN EN 1062-7
lVT+V (B4.2)
Grip and slip resistant DIN EN 13036-4, DIN 51130
55 Skt R11-V4 and R12-V6 or R13 V10
Chemical resistance DIN EN 13529
Test liquids DiBT No. 1, 3, 10
Abrasion resistance (H22 Wheel) DIN ISO 9352, ASTM D 1044
<1500 mg/1000 U
Impact resistance DIN EN ISO 6772-2
4 Nm - no cracks
Fire class EN 13501-1
Bfl-s1
