Dencryl Bridge Pedestrian

(5-6 mm)

Exposed waterproofing membrane layer as wearing layer
Safety and durability is essential for pedestrian and cycle bridges. Dencryl Bridge Pedestrian bonds with the substrate and provides a sealed wear layer in combination with a flexible, crack-bridging barrier membrane and surface friction suited for walking and cycling. Dencryl Bridge Pedestrian provides a low density option to provide a wear, impact and abrasion resistant surface that will offer corrosion resistance, slip resistance and limited maintenance requirements. It can be used on new bridge construction, routine maintenance or bridge restoration applications. Dencryl Bridge Deck Systems are only installed by authorised and approved applicators.



Benefits

  • Will adhere well to dry and clean surfaces including steel and pipe outlets etc.
  • Will resist rain and snow within 45–60 minutes of installation
  • Bond of membrane in excess of concrete tensile or cohesive strengths.
  • Flexibility sufficient to bridge cracks in excess of 3.5 mm in well below freezing conditions.
  • Very easily repaired if damaged.
  • Rapid setting and curing enables rapid handover.

Applications

Bridges are continuously exposed to severe stresses and typical factors affecting their longevity, include inadequate protection specified at design phase, quality and handling of concrete and/or steel, physical and chemical exposure, climatic conditions, traffic types and frequency and regularity and quality of maintenance. Dencryl Bridge Deck Waterproofing systems provide 100% effective seamless waterproofing thereby denying entry of water, chloride and de-icing salts from permeating into and percolating through the structural concrete deck and thus preventing the steel reinforcement corroding. This also includes corrosion inhibition of orthotropic steel decks etc. where these are the decks of choice.

Scope of use

  • Roof decks
  • Pedestrian and cycle bridges

Application conditions

  • Temperature -30ºC to 30ºC, best 15 to 25ºC, max. moisture content in the concrete subfloor 5% by weight.

Appearance

  • Dencryl Bridge pedestrian is an antislip singlecoloured bridge covering system. The slip resistance might be varied from moderate to pronounced.

Temperature Resistance

  • Dencryl Bridge pedestrian is resistant to temperature cycles up to 80°C. Extended periods at these temperatures and above will make material susceptible to chemical attack and abrasion wear.

Life Expectancy

  • more than 30 years

Colours

  • See separate color chart.
Dencryl Bridge Pedestrian
CE
Bridge Deck OS 11 A

System Build-up

LAYER PRODUCT CONSUMPTION (kg/m²) INTERMEDIATE THICKNESS (mm) APPLICATION
Primer Dencryl P11/P12 (Depending on substrate) 0.3 - 0.5 Light sand scatter 0.3 - 0.8mm on wet surface Min 0.3 Rubber squegee and paint roller
Membrane Dencryl M42 min 2.8 None Min 2.0 Notched rubber squegee
Wear layer Dencryl M42 + aggregate min 2.8 + aggregate broadcast Min 3.0 Notched rubber squegee
Topcoat Dencryl S31 0.7 -1.2 None 0.5 - 0.8 Rubber squegee and paint roller

Technical Data

Properties

Value

Fully cured at 20°C

2 hours

Applied thickness

5 - 6 mm

Water Permeability

Nil – Karsten test (impermeable)

Hardness

SHORE D 80

Compressive strength

85 MPa

Reaction to fire

Dfl-s1

Bond strength

>1.5 MPa

Temperature resistance

Up to 80°C at 4 mm

Thermal expansion coefficient

<40 ppm

Abrasion resistance

50 mg / 1000 cycles (Taber Abrader)

Thermal conductivity

< 0,4 W/m·K

Anti-slip according to DIN 51130

R9 – R13

Colours

Yellow
Buff
Red
Blue
Dark Green
Dark Grey
Light Grey
