Dencryl Bridge

(6-10 mm)

PMMA acrylic flooring system.
Recommended for indoor and outdoor areas, which are subject to extremely heavy mechanical charges, and is therefore used for road bridges, parking decks, driving ramps, loading areas, indoor industrial areas with exceptionally heavy charges, or other places where a floor with extremely high resistance to wear and strokes is required.








Benefits

  • Very Good Chemical Resistance
  • Weatherproof & UV Resistant
  • Fast Installation
  • Curing Down to -30°C
  • Low Maintenance Cost
  • Non Slip Seamless & Flexible Finish
  • Damp Proof Membrane Layer

Applications

For all types of exterior use and extremely heavy loaded industrial floors, in combination with high demands to flexibility. Dencryl Bridge offers high wearability, impact and chemical resistant. The very fast curing of Dencryl Bridge means, that eventual traffic blocking time is minimized while installing the system.

Scope of use

  • Road bridges
  • Parking decks
  • Driving ramps
  • Loading areas

Application conditions

  • Temperature -30ºC to 30ºC, best 15 to 25ºC, max. moisture content in the concrete subfloor 5% by weight.

Appearance

  • Dencryl Bridge is a rough single coloured bridge covering system. The slip resistance might be varied from moderate to pronounced.

Temperature Resistance

  • Dencryl Bridge is resistant to temperature cycles up to 80°C. Extended periods at these temperatures and above will make material susceptible to chemical attack and abrasion wear.

Life Expectancy

  • 20 - 30 years.

Colours

  • See separate color chart.
Dencryl Bridge
CE
Bridge Deck OS 11 A

System Build-up

LAYER PRODUCT CONSUMPTION (kg/m²) INTERMEDIATE THICKNESS (mm) APPLICATION
Primer Dencryl P11 0.3 - 0.5 Scatter Quartz 0.7 - 1.2 mm on wet surface Min 0.5 Rubber squegee and paint roller
Membrane Dencryl M42 2.0 - 3.0 none Min 2.0 Notched rubber squegee spike roller
Wear layer Dencryl M42 4 + 8 kg bauxite Scatter Bauxite on wet surface Min 6.0 Spike metal rake and trowel board
Sealcoat Dencryl S31 1.0 - 2.0 None 1.0 - 1.5 Rubber squegee and paint roller

Technical Data

Properties

Value

Fully cured at 20°C

2 hours

Applied thickness

6 - 10 mm

Water Permeability

Nil – Karsten test (impermeable)

Hardness

SHORE D 80

Compressive strength

85 MPa

Reaction to fire

Dfl-s1

Temperature resistance

Up to 80°C at 6 mm

Thermal expansion coefficient

<40 ppm

Abrasion resistance

50 mg / 1000 cycles (Taber Abrader)

Anti-slip according to DIN 51130

R9 – R13

Food Contact

No contamination

Colours

Yellow
Buff
Red
Sky Blue
Dark Green
Light Grey
Mid Grey
Black
