Dencryl Park Deck OS 14

(6-8 mm)

Fast curing car park deck coating system with separate, manually applied waterproofing membrane and wear coat with enhanced crack bridging properties (class B 4.2) and lVT+V (-20°C) for multi storey car parks for exposed and intermediate decks and sidewalks on bridges with pedestrian and vehicle traffic. According to RILI SIB 2001, class OS 14 and DIN 18532 Part 1 and 6.







Benefits

  • Fast Installation
  • Curing Down to -30°C
  • High Abrasion Resistance
  • Anti Slip Finish Available
  • High Impact Resistance
  • Good Chemical Resistance
  • Seamless & Clean Look
  • Increased dynamic crack bridging

Applications

A weatherproof & UV Resistant heavy duty car park deck coating system designed for outdoor parking areas and open multi-level parking houses. The system consists of 2 separate layers of membrane, a fiber reinforced fleece and a strong and very durable top layer. The system offers excellent crack bridging properties and flexibility. Due to the unique properties of the PMMA binder, the system can be installed in only 2 hours, regardless the temperatures.

Scope of use

  • Parking decks
  • Driving ramps
  • Loading areas
  • Roof decks

Application conditions

  • Temperature -30ºC to 30ºC, best 15 to 25ºC, max. moisture content in the concrete subfloor 5% by weight.

Appearance

  • Dencryl Park Deck is a smooth or antislip single or multi coloured Park Deck system. The slip resistance might be varied from moderate to pronounced.

Temperature Resistance

  • Dencryl Park Deck is resistant to temperature cycles up to 80°C. Extended periods at these temperatures and above will make material susceptible to chemical attack and abrasion wear.

Life Expectancy

  • 10 - 20 years.

Colours

  • See separate color chart.
Dencryl Park Deck OS 14
Park Deck OS 14
CE

System Build-up

LAYER PRODUCT CONSUMPTION (kg/m²) INTERMEDIATE THICKNESS (mm) APPLICATION
Primer Dencryl P11/P12 (Depending on substrate) 0.3 - 0.5 Light sand scatter 0.3 - 0.8mm on wet surface Min 0.3 Rubber squegee and paint roller
Membrane Dencryl M42 1.5 - 2.0 Reinforced fiber fleece (optional) Min 2.0 Notched rubber squegee
Membrane Dencryl M42 1.5 - 2.0 None Min 2.0 Notched rubber squegee
Wearcoat Dencryl M42 1.5 - 2.0 + Quartz Sand broadcast Min 3.0 Trowel and notched rubber squegee
Topcoat Dencryl S32 0.6 - 0.9 None 0.5 - 0.7 Rubber squegee and paint roller

Technical Data

Properties

Value

System thickness

Aprox 6 - 8 mm

Adhesive strength at Tnorm DIN EN 1542

≥ 4.0 N/mm2

Adhesive strength after freeze-thaw with de-icing salt DIN EN 13687-1 and -2

≥ 2.3 N/mm2

Dynamic crack bridging (-20°C) DIN EN 1062-7

lVT+V (B4.2)

Grip and slip resistant DIN EN 13036-4, DIN 51130

55 Skt R11-V4 and R12-V6 or R13 V10

Chemical resistance DIN EN 13529

Test liquids DiBT No. 1, 3, 10

Abrasion resistance (H22 Wheel) DIN ISO 9352, ASTM D 1044

<1500 mg/1000 U

Impact resistance DIN EN ISO 6772-2

4 Nm - no cracks

Fire class EN 13501-1

Bfl-s1

Colours

Yellow
Buff
Red
Blue
Dark Green
Dark Grey
Light Grey
